- Pic16f72 microcontroller programmed
- Mosfet technology
- Battery- 2 battery system
- Input dc range- 21 v ~ 28.4 v
- Efficiency (on battery mode) :> 84%
- Protection overload – 100%
- Short cicuit- 300%
- Charging current – 5 amp to 12 amp
- High frequency charging
- Power factor correction
- Indication – low battery shut down with beep
- Technical specification :
- Mains AC Lower Voltage Limit
100V+/- 5V in Inverter Mode
180V+/- 5V in UPS Mode- Mains AC Higher Voltage Limit
280V+/- 10V in Inverter Mode
260V+/- 5V in UPS Mode- Output Voltage at No Load
220V +/-7V AC - Output Wave Form at No Load (for SINE WAVE)
Sine Wave - Home UPS Output Frequency
50+/-1.0Hz - Change over time Mains to UPS and vice versa
< 3 msec
